Customized Aluminium Honeycomb Core Sawing Machine
Power Supply:380V/50Hz or Customized
Cutting Height:500mm
Cutting Width: 50mm
Cutting Precision: within ±0.05mm
Spindle Presicion: within 0.05mm
Aluminium Honeycomb Panels, Honeycomb Cores
Production Introduction
Customized Aluminium Honeycomb Core Sawing Machine
1. The thickness of the
core board is guaranteed to be 2600mm in length, 500mm in width and 0-80mm in thickness
(can be designed and produced upon request).
2. Smooth and clean cutting surfaces
3. PLC automatic control, touch screen man-machine control.
4.Table top 20mm thick, work surface channel reinforced, guaranteed within 600mm spacing, surface milled, operating surface height 80mm.
5. Trolley slide with 45# linear guide, length according to actual requirements.
6. Spindle motor 7KW, 380V, max. speed 6000 rpm.
7. Pushing motor with double servo 1.5kw, 220V
8. Moving stepper motor 400w, 380V
9. Air pressure requirement: 0.6MPa
10. Dimension: 4000*2500*2000mm
