新 auto spraying machine 在 江苏省, 中国
新
Doubleclick to zoom in
请联系卖家咨询
更多照片和设备细节。
规格参数
- 新旧状况
- 新
- Hits
- 7982
- No
- Part
- Spraying house detail
- Turntable power
- Speed inverter control
- 0-30times/min
- Diameter of turntable
- 800mm
- Slip ring number
- 14 round
- Electric valve
- Three way
- Electric valve pressure
- 24v DC
- Sealing method and material
- Teflon
- Compressor air
- 4cbm/min
- Pressure request
- 8kg/cm2
- Pump pressure request
- 1-4kg/cm2
- Distance between gun and wire
- 100-150mm
- Distance between gun beside and spraying house
- >70cm
- Distance between gun left or right and spraying house
- >25
- Spraying house height
- 210-224cm
- House stainless steel thickness
- 1.5mm
- House support thickness
- 3mm
- House wall thickness
- 1.5mm
- Dedusting unit
- dedusting house size
- Dedusting power
- 4-7.5kw,0.7-0.75
- Windy control
- Filter and board
- Spraying number and diameter
- 30/group,diameter 5mm
- Water request for dedusting
- 0.3-0.5 cmb
- Water change time
- Every 2 weeks
- Water pump and lift
- 40-60t/h ;0.9m
- Diameter of dedusting pipe
- 2inch
- Diameter of joined dedusting pipe
- 2inch
- Dedusting request
- Do same time with water change
- Feed table length of pipe
- 1.8-2.4m
- Conveyor
- Photo trace distance
- Diameter of roller
- 219mm
- Bearing model
- Ucp210=214
- Single wire density
- 20mm
- Inverter motor power
- 4kw
- Gear box
- cycloidal needle wheel type motor
- Speed of gear box
- 0-20m/min
- Washing unit
- Washing unit power
- Washing unit rotary speed
- 80runs/min
- Washing diameter of roller
- 170mm
- Washing tank water change time
- Every day more than one time
- Distance between oven and ground
- 1800mm
- Oven detail
- Height of oven house
- Distance between line and oven
- 900-950mm
- Distance with fan over and line
- 150-170mm
- Oven power
- 0.75kw,8000m3/h
- Oven temperature
- 80-100 degree
- Humidity fun
- 1-2 pc
- Fan power
- 0.55kw
- Radiator detail
- Seamless ,thickness>2.5mm,diameter 25-30mm,9 pcs,length 190cm
- Area of radiator
- 8-9m2
- Oven control system
- Sensor, controller ,electric valve ,pump
- Surface deal with
- Pressure >kg,hot zinc
- Condensate water
- Recycling deal with
- Radiator sealing
- asbestos
- Over size more than oven
- 300mm
- Cooling fan power
- 0.5kw/pc
- Others
- Group for wire
- Total power
- 18-22kw
- Feed table length
- 180-240cm
- Out table length
- 200-240cm
- Washing line length
- 250-260cm
- Spraying house length
- 360-560cm
- Spraying house width
- 300-470cm
- Total length
- 19.9-28m
- 分类
- 皮革 在 中国
- 子类别
- Machinery
- 产品编号
- 80097688
描述
No
Part
Description
remark
SPRAYING HOUSE DETAIL
Turntable power
0.75-1.1kw
Speed Inverter control
0-30times/min
Diameter of turntable
800mm
Slip ring number
14 round
Electric valve
Three way
Electric valve pressure
24v DC
Sealing method and material
Teflon
Compressor air
4cbm/min
Pressure request
8kg/cm2
Pump pressure request
1-4kg/cm2
Distance between gun and wire
100-150mm
Distance between gun beside and spraying house
>70cm
Distance between gun left or right and spraying house
>25
Spraying house height
210-224cm
House stainless steel thickness
1.5mm
+/-0.1-0.2
House support thickness
3mm
+/-0.1-0.3
House wall thickness
1.5mm
+/-0.1-0.2
Dedusting unit
dedusting house size
1600x1000x2030mm
One group size
Dedusting power
4-7.5kw,0.7-0.75
Windy control
Filter and board
Spraying number and diameter
30/group,diameter 5mm
