新 BEAM 1.0 (Z4) 在 米兰, 伦巴第, 意大利

规格参数

新旧状况
Flow rate (max)
1.0 l/min
Outlet pressure (min)
/
Outlet pressure(max)
1.2 bars
Total hydrocarbon content
< 0.05ppm
Start-up time
50 min
Max inlet hydrocarbon content
100 ppm
Min supply pressure
Integrated Pump
Rs232
Standard
Supply voltage
100-240Vac 50/60Hz
Connection type
IEC320-C13
Installation power (max)
240W (280VA)
Fuse rating (5x20mm)
2A
Dimensions
Standard 19″ – 4U
Net weight
<13 kg
Outlet port
6 mm Push-Fit
Inlet port
6 mm Push-Fit
Health connectot
max 5A, 40VDC MAX / 24VAC MAX (normaly closed)
Temperature (min;max)
5-35°C (41-95°F)
Humidity (max, non condensing)
80% at 25°C (77°F)
Noise
<25dB (A)
Ip rating
IP20
产品编号
59850203

描述

The BEAM 1.0 performs in 24/7 production process worldwide with utmost reliability. Even under the most challenging environments Beam 1.0 guarantee frictionless industrial use for different applications (example: high power UV-lasers (>300 nm)). The Generator produces a continuous flow of hydrocarbon-free air. The flow is controlled stable. All Generators reduce the total quantity of hydrocarbons to less than 0,01 ppm, establishing a stable flow for your application. Zero-air produced in this way replaces existing stocks of synthetic air stored in high pressure bottles.Laser Gas Generators are designed specifically to supply clean, dry, hydrocarbon-free air to be used for several applications.LNI Swissgas recognizes the importance of having a safe, reliable and cost effective supply of high-purity Zero addition providing flexibility to add or remove modules as your application requirements evolve over time.

请向卖家询价

品牌
LNI Swissgas
类型
实验室气体发生器
位置
🇮🇹 米兰, 伦巴第, 意大利
