新 BEAM 1.0 (Z4) 在 米兰, 伦巴第, 意大利
新
Doubleclick to zoom in
请联系卖家咨询
更多照片和设备细节。
规格参数
- 新旧状况
- 新
- Flow rate (max)
- 1.0 l/min
- Outlet pressure (min)
- /
- Outlet pressure(max)
- 1.2 bars
- Total hydrocarbon content
- < 0.05ppm
- Start-up time
- 50 min
- Max inlet hydrocarbon content
- 100 ppm
- Min supply pressure
- Integrated Pump
- Rs232
- Standard
- Supply voltage
- 100-240Vac 50/60Hz
- Connection type
- IEC320-C13
- Installation power (max)
- 240W (280VA)
- Fuse rating (5x20mm)
- 2A
- Dimensions
- Standard 19″ – 4U
- Net weight
- <13 kg
- Outlet port
- 6 mm Push-Fit
- Inlet port
- 6 mm Push-Fit
- Health connectot
- max 5A, 40VDC MAX / 24VAC MAX (normaly closed)
- Temperature (min;max)
- 5-35°C (41-95°F)
- Humidity (max, non condensing)
- 80% at 25°C (77°F)
- Noise
- <25dB (A)
- Ip rating
- IP20
- 产品编号
- 59850203
描述
The BEAM 1.0 performs in 24/7 production process worldwide with utmost reliability. Even under the most challenging environments Beam 1.0 guarantee frictionless industrial use for different applications (example: high power UV-lasers (>300 nm)). The Generator produces a continuous flow of hydrocarbon-free air. The flow is controlled stable. All Generators reduce the total quantity of hydrocarbons to less than 0,01 ppm, establishing a stable flow for your application. Zero-air produced in this way replaces existing stocks of synthetic air stored in high pressure bottles.Laser Gas Generators are designed specifically to supply clean, dry, hydrocarbon-free air to be used for several applications.LNI Swissgas recognizes the importance of having a safe, reliable and cost effective supply of high-purity Zero addition providing flexibility to add or remove modules as your application requirements evolve over time.
