规格参数
- 新旧状况
- 新
- Flow rate (max)
- 1500 cc/min3000 cc/min
- Outlet pressure (min)
- 5.5 bars (79,7 psi)
- Nitrogen purity *1
- 99,9999% (Hydrocarbons <0.01 ppm)
- Outlet dew-point
- <-60°C (-76°F)
- Outlet particulate
- 0.01 micron
- Rs485
- Standard
- Rs232
- Standard
- Supply rating
- 100-115 Vac 50/60 Hz or 220-240Vac 50/60Hz
- Connection type
- IEC320-C13
- Installaton power (max)
- 1000W
- Fuse rating (5x20mm)
- 6.3 A
- Net weight
- <60 kg
- Dimensions
- 430 x 580 x 630 (mm)
- Outlet port
- 1/8″ female BSPP
- Working temperature
- 5-35°C (41-95°F)
- Storage temperature
- 1-50°C (34-122°F)
- Humidity (max, non condensing)
- 70%
- Noise
- <58 dB(A)
- Ip rating
- IP20
- Pullution degree rating
- 2 (with no aromatic compunds)
- Altitude
- < 2000m
- 产品编号
- 59850178
描述
The BEAM 4 series perform in 24/7 production process worldwide with utmost reliability. Even under the most challenging environments BEAM 4 series guarantee frictionless industrial use for different applications (example: high power UV-lasers <266 nm / Optical Parametric Amplifiers). The Generator produces a continuous flow of Nitrogen with High Purity Laser Grade. The BEAM 4 series has been developed to meet specific requirements in term of gas, flow, purity and pressure for Laser applications. This generator is equipped with a smart low noise built-in pistons compressor, 100% oil-free.
The BEAM 4 series remove oxygen from air to less than 5 ppm and HC pollutants to less than 0.1ppmLNI Swissgas recognizes the importance of having a safe, reliable and cost-effective supply of high reliable Nitrogen for addition, providing flexibility to add or remove modules as your application requirements evolve over time.
