26.5 GHz Frequency Counter
The EIP 578 is a 10 Hz to 26.5 GHz Multi-functional Microwave Frequency Counter. The 578 can tune and phase lock an external Signal Source over a wide range of frequencies. HPIB interface for automatic systems is included as standard equipment.
-Band 1:
Frequency range: 10 Hz....100 MHz; BNC (f)
Impedance: 1 Mohms / 20 pF
Sensitivity: 25 mV rms
-Band 2:
Frequency range: 10 MHz....1 GHz; BNC (f)
Impedance: 50 ohms
Sensitivity: -20 dBm
-Band 3:
Frequency range: 1 GHz....26,5 GHz; APC-3.5 (f)
Impedance: 50 Ohm
Sensitivity:
***1GHz....12.4 GHz = -30 dBm
***12.4 GHz....18 GHz = -25 dBm
***18 GHz....22 GHz = -20 dBm
***22 GHz....26.5 GHz = -15 dBm
Options:
Option 01: D to A Converter
Option 02: Power Measurement
Option 03: Oven Timebase
Option 05: High Stability Oven Timebase
Option 06: Extended Frequency
Option 09: Rear Input
Option 10: Chassis Slides
制造商: EIP
模型: 578
