新 成工 Vtl250/250A 数控立式车床 在 温州市, 浙江省, 中国
新
Doubleclick to zoom in
请联系卖家咨询
更多照片和设备细节。
规格参数
- 新旧状况
- 新
- 最大回转直径
- 2500 mm
- Max.turning diameter
- 2500 mm
- 工件最大高度
- 2000/2000 mm
- Max.weight of workpiece
- 16000 kg
- Max.torque of worktable
- 28000 牛米
- X/z 位置精度
- 0.02/0.020 mm
- X/z 重复位置精度
- 0.01/0.01 mm
- 工作台速度调节块
- 无级变速,带两个模块
- 连续额定
- 45 kW
- X 轴行程
- -200 ~ +2000 毫米
- Z轴行程
- 800/1200 mm
- 送料速度快
- 8000 mm/min
- 梁式起重装置距离
- 4×250 mm
- 车削刀具尺寸
- 40×40 mm
- 电压波形范围
- -10 ~ +10
- 频率
- 50 Hz
- 总功率
- 95 kW
- 机器重量
- 47000 kg
- 机器整体尺寸(长×宽×高)
- 7800×6200×7350 mm
- 子类别
- 车床
- 产品编号
- 106130575
描述
The series VTL is new design product for the market demand for solving the key processing technology. It is moving beam single column CNC vertical lathe with new structure design, technology research, machine debugging etc. It is suitable for power generation, shipbuilding, metallurgy, mining and other industries of large parts processing
The series VTL is new design product for the market demand for solving the key processing technology. It is moving beam single column CNC vertical lathe with new structure design, technology research, machine debugging etc. It is suitable for power generation, shipbuilding, metallurgy, mining and other industries of large parts processing.
1.The main parts use the China and foreign famous brand like the CNC control system, main electric parts, main bearings, ball screw, main hydraulic parts etc.
2.The introduction of mature technology, reliable selection of imported fittings, and our advanced processing, testing ways, to ensure that the machine has high machining accuracy, high rigidity, high reliability, and have a feature of rational layout, convenient operation, high automation degree etc. Machine can match organic to tool device, can realize automatic tool change device, automated processing, improve the processing quality, and reduce operating costs.
